MP2020 Electronic Box

This easy-to-use electronic box lets you control and manage your Precimeter inductive sensors.

arrow icon
4 adjustable level switches
Control inductive sensors with 4 adjustable level switches
arrow icon
Dual measurements
Manage level measurement and internal temperature
arrow icon
Flexible setup
Option to add ethernet protocol communication
arrow icon
Easy to use
Simple display (level: 0–100%), with key controls

Product Information

The MP2020 electronic box, dedicated for our CLP, PLP and RP inductive sensors with digital display. It can be used connected to a PLC-based control system or to a separate/standalone indicator system.

Advantages with MP2020 extension

Technical Specifications

Power Requirement
24 VDC < 1 A
Display
0-100%
Level measurement
4-20mA
Level switching outputs
4 switches NO/NC
Internal Temp Output
4–20 mA (0–100°C, 32–212°F)
Alarms
Temp alarm GND, General alarm 1 switch NO/NC
Operating temperature
-25C - 65C Ethernet
Ethernet Protocol
Optional (Profinet, Ethernet IP or Modbus TCP)
